VS 3000 Specimen preparation
MonTech · Specimen preparation
The VS 3000 universal constant volume cutter is the ideal and reliable sample preparation tool for applications that require constant volume samples such as preforms for moulding operations. The VS 3000 sample cutter can be tted with knives of any diameter between 20 and 60mm per customer requirements, making the cutter an ideal tool for easy preform preparation.
เอกสารดาวน์โหลด
- MonTech General Cataloguemontech-product-catalogue-2023.pdfดาวน์โหลด PDF
- MonTech Specimen and Die cuttingmontech-specimen-and-die-cutting-2021.pdfดาวน์โหลด PDF
ข้อมูลจำเพาะ
| Cutting diameter | per customer requirement 20 to 60 mm |
|---|---|
| Max. thickness | 18 mm |
| Reproducibility | 0.1 % |
| Sample volume (adjustable) | 2 cm³ to 80 cm³ (depending on knife) |
| Compression time (adjustable) | 1 sec to 30 sec |
| Dimensions (H x W x D) | 1120 mm x 400 mm x 390 mm |
| Weight | approx. 90 kg net |
| Pneumatics | min. 5.0 Bar |
| Cutting diameter in mm | per customer requirement 20 to 60 |
| Sample volume | 2 cm³ to 80 cm³ (adjustable) (depending on knife) |
| Compression time | 1 sec to 30 sec (adjustable) |
