P-VS 3000 Die and Sample cutting

รุ่นP-VS 3000

MonTech · Die and Sample cutting

P-VS 3000 Universal sample cutter for fast and precise preparation of sample test specimens for tensile tests and all other DIN, ISO and ASTM standard sample shapes from rubber, elastomers, foam rubber, plastic lms, foils and paper. Any type of cutting knife can be used with the P-VS 3000 sample cutter. Knives can be changed in seconds and cutting height can easily be adjusted.

ขอใบเสนอราคา

เอกสารดาวน์โหลด

ข้อมูลจำเพาะ

Cutting force	8 kN
Cutting stroke	30 mm
Max. material thickness / hardness	8 mm / 95 Shore A
Reproducibility	0.1 %
Compatible cutting knives	Any ISO, DIN, ASTM and other standard die types
Dimensions (H x W x D)	440 mm x 300 mm x 380 mm
P-VS Sliding Dimensions (H x W x D)	460 mm x 300 mm x 1050 mm
Weight	approx. 50 kg net
Pneumatics	min. 5.0 Bar
P-VS Options: Sliding table	and multiple knife stations
Designed to simultaneously cut	multiple samples from the
same rubber sheet for increased	productivity.
Description	Universal Sample cutter
Die height	20 – 50 mm
Throat depth	120 mm
Cutting area	250 x 100 mm (250 x 125mm optional)
P-VS sliding table Dimensions (H x W x D)	460 x 300 x 1050 mm
Pneumatics (recommended line pressure)	min. 5.0 Bar

ตารางเปรียบเทียบรุ่น

P-VS 3000 die cutter / clicker press series - comparison (SpecimenCutting 2021, p. 3)

Specification	P-VS 3000 M	P-VS 3000	P-VS 3000 Plus	P-VS 3000 L	P-VS 3000 L Plus
Description	Manual sample cutter	Universal Sample cutter	High force sample cutting press	Large working area universal sample cutter	High force large working area sample cutting press
Cutting force	3.8 kN	8 kN	15 kN or 40kN	8 kN	15 kN or 40kN
Cutting stroke	30 mm	30 mm	30 mm	30 mm	30 mm
Die height	20 – 150 mm	20 – 50 mm	20 – 50 mm	20 – 50 mm	20 – 50 mm
Throat depth	70 mm	120 mm	120 mm	180 mm	180 mm
Cutting area	120 x 80 mm	250 x 100 mm (250 x 125mm optional)	250 x 100 mm (250 x 125mm optional)	370 x 200 mm	370 x 200 mm
Max. material thickness / hardness	6 mm / 95 Shore A	8 mm / 95 Shore A	10 mm / 98 Shore A (15kN); 10 mm / 70 Shore D (40kN)	8 mm / 95 Shore A	10 mm / 98 Shore A (15kN); 10 mm / 70 Shore D (40kN)
Compatible cutting knives	Any ISO, DIN, ASTM and other standard die types	Any ISO, DIN, ASTM and other standard die types	Any ISO, DIN, ASTM and other standard die types	Any ISO, DIN, ASTM and other standard die types	Any ISO, DIN, ASTM and other standard die types
Reproducibility	0.1 %	0.1 %	0.1 %	0.1 %	0.1 %
Dimensions (H x W x D)	380 x 120 x 180 mm	440 x 350 x 380 mm	690 x 350 x 380 mm	440 x 470 x 500 mm	690 x 470 x 500 mm
P-VS sliding table Dimensions (H x W x D)	–	460 x 300 x 1050 mm	460 x 300 x 1050 mm	–	–
Weight	14 kg	50 kg	72 kg (15kN); 108 kg (40kN)	78 kg	100 kg (15kN); 146 kg (40kN)
Pneumatics (recommended line pressure)	–	min. 5.0 Bar	min. 5.0. Bar	min. 5.0. Bar	min. 5.0. Bar
